| VACUNITE® | System throughput | Reference IV performance* | Total energy consumption** (0.35 kwh/kg) | Nitrogen consumption | Flake reactor vacuum | Flake reactor performance | Extruder | Pellet form | SSP powered by POLYMETRX | Final pellet quality | Space needed | Height / SSP height |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Model | Maximum [kg/h] | [dl/g @ kg/h] | [kWh/h] [ | [Nm³/kg] | Advantages | Residual moisture Food grade | L/D drive rating [kW] | Granumetry | Type | AA level VOCs | [m²] [ | [m / m] |
| VACUNITE® 1714 T - 1000 | -1250 | 0.82 @ 1000 | 350 | 0.085 | < 10 redundant filter | Residual moisture < 50ppm several national and international approvals |
~ 27 160 kW |
spherical inline crystallised | FIFO vacuum-supported N2-SSP | < 1 ppm brand owner OK | 270 | 5.5 / 14 |
| VACUNITE® 1716 T - 1500 | -1500 | 0.82 @ 1300 | 455 | 0.085 | < 10 redundant filter | ~ 27 200 kW |
spherical inline crystallised | FIFO vacuum-supported N2-SSP | < 1 ppm brand owner OK | 320 | 6.5 / 16 | |
| VACUNITE® 2018 T - 1500 | -1875 | 0.82 @ 1550 | 543 | 0.085 | < 10 redundant filter | ~ 27 315 kW |
spherical inline crystallised | FIFO vacuum-supported N2-SSP | < 1 ppm brand owner OK | 380 | 7.5 / 16 | |
| VACUNITE® 2318 T - 1500 | -1875 | 0.82 @ 1800 | 630 | 0.085 | < 10 redundant filter | ~ 27 315 kW |
spherical inline crystallised | FIFO vacuum-supported N2-SSP | < 1 ppm brand owner OK | 380 | 7.0 / 16 | |
| VACUNITE® 2321 T - 2000 | -2500 | 0.82 @ 2100 | 735 | 0.085 | < 10 redundant filter | ~ 27 355 kW |
spherical inline crystallised | FIFO vacuum-supported N2-SSP | < 1 ppm brand owner OK | 400 | 7.0 / 16 | |
| VACUNITE® 2621 T - 2000 | -2500 | 0.82 @ 2350 | 823 | 0.085 | < 10 redundant filter | ~ 27 400 kW |
spherical inline crystallised | FIFO vacuum-supported N2-SSP | < 1 ppm brand owner OK | 480 | 9.0 / 14 |
* At an input flake IV of 0.76 dl/g
** including expected power consumption of necessary water chillers at the customer´s plant
